Universal terminal AL/CU for use in low voltage switchboards (1kV)

- 50 mm nominal Cross-section
- 2 wire outputs
- Current carrying capacity 240/415 [A]
- Rated insulation voltage (Ui) 500 [V]
- Rated impulse withstand voltage (Uimp) 6 [kV]
- Surge Voltage 160 [A]
- Aluminum
- PA6.6 insulator
We are the manufacturer with high knowledge of our product. Both technicals and prices are suited individually. Quote your demand below.
- Grey - ZP-50/SZ - 0250100050101
- Blue - ZP-50/N - 0250100050102
- Green - ZP-50/ZZ - 0250100050103
- Packed by 10 - 0,460 [Kg]
- Packed by 300 - 13,80 [Kg]
